36054 Traxxas Stampede 1/10 2wd XL-5 Brushed Green - ARTR (requires battery + Charger)
Stampede 1/10 Scale 2wd Monster Truck
Traxxas Stampede RC Monster Truck Rock-Crushing Torque And Waterproof!
The best-selling Traxxas Stampede is the original high performance monster truck. Its legendary ruggedness has made the Stampede name synonymous with off-road fun. Today, the Stampede has a bold look, innovative features, and of course, more power. With a top speed of 30+mph and a tall drive-over-anything ground clearance, Stampede rips through grass and powers over curbs. Waterproof electronics allow it to blast through puddles and shred snow for all-weather adventure. Step up to genuine Traxxas quality and performance and discover a whole new level of fun with the Traxxas Stampede!
Modified Muscle
The Titan 12T 550 modified motor pumps out incredible mod-motor power with virtually maintenance-free operation, and long-lasting performance. The Titan's integrated cooling fan pulls cool air through vent tunnels molded into the motor plate to keep temperatures down. A cooler running motor equates to faster speeds, longer runtime, and extended motor life. The XL-5 Electronic Speed Control offers high current handling, EZ-Set one-button setup, and smooth high-frequency control. Once reserved for high-end replacement ESCs, the XL-5 comes standard with three drive profiles, low voltage detection, thermal shutdown protection, gold-plated connectors, and incredibly low resistance. The patented Traxxas High-Current Connector opens the door for unrestricted current flow with today's high-power batteries.
Sealed Electronics Extend Your Driving Fun
The Stampede's exclusive watertight, sealed electronics provide the freedom to drive through water, mud, snow, and other wet-running conditions. The XL-5 electronic speed control and the mini receiver are sealed against the elements. It opens up a whole new world of adventure and fun.
100% Assembled and Ready for your Battery and Charger
The Stampede rolls out of the box fully assembled and Ready-To-Race with the TQ 2.4GHz 2-channel radio system, waterproof XL-5 Electronic Speed Control and Titan 12T motor. No other truck combines Traxxas' level of support with unparalleled parts availability. We're here to ensure that your RC experience is enjoyable, easy, and fun!
Features:
- Traxxas TQ 2.4GHz radio system
- Waterproof electronics permit driving in water, mud and snow
- High-torque Waterproof Traxxas #2056 steering servo
- Monstrous 4-inches of ground clearance
- Top speed over 30mph
- Powerful Titan 12T 550 modified motor with internal cooling fan
- High-performance waterproof XL-5 Electronic Speed Control
- Innovative watersealed design
- Three Drive Profiles
- Sport Mode - Forward / Brake / Reverse
- Race Mode - Forward / Brake
- Training Mode - 50% Forward / Brake / 50% Reverse (patented)
- 12-Turn motor limit for 550 size motors
- 15-Turn motor limit for 540 size motors
- Integrated on/off switch
- Traxxas EZ-Set one-button setup
- LiPo and NiMH compatible with two-stage low-voltage detection
- High-efficiency MOSFET transistors
- Speed control and receiver are securely screwed to the chassis
- Efficient Magnum 272 three-gear transmission with ball bearings
- Sealed gearbox protects the transmission with beefed up motor guard for extra protection
- Torque-Control slipper clutch system
- External gear cover with easy slipper access
- Reliable planetary gear differential
- Efficient telescoping U-joint driveshafts
- Fiber-composite monocoque chassis
- Easy access battery compartment
- Fully adjustable Ultra Shocks with X-ring technology
- White powder coated shock springs feature a responsive spring rate
- Durable solid camber links eliminate the need for adjustment
- Captured rod ends won't pop off for superior durability
- Talon 2.8" tires are pre-glued on stunning mirror-chrome 2.8" All-Star wheels
- Performance foam tire inserts
- ProGraphix multi-colored painted body
Vehicle Specs | |
---|---|
Length: | 16.25 inches (413 mm) |
Front Track: | 12.75 inches (324 mm) |
Rear Track: | 12.75 inches (324 mm) |
Weight: | 65.3 ounces (1.85 kg) |
Height (overall): | 9.5 inches (241 mm) |
Wheelbase: | 10.63 inches (270 mm) |
Front Shock Length: | Long |
Rear Shock Length: | XXLong |
Front Tires (pre-glued): | Talon 2.8" |
Rear Tires (pre-glued): | Talon 2.8" |
Front Wheels: | 2.8" Mirror-Chome (All-Star) |
Rear Wheels: | 2.8" Mirror-Chome (All-Star) |
Electronic Speed Control: | XL-5 Electronic Speed Control |
Motor (electric): | Titan 12T 550 (12-Turn) |
Steering Servo: | #2056 High Torque Waterproof |
Transmitter: | TQ 2.4GHz Radio |
Receiver: | #6519 3-Channel Micro |
Gear Ratio (internal): | 2.72 (final drive: 12.34) |
Differential Type: | Planetary |
Gear Pitch: | 48-Pitch |
Transmission: | Magnum 272 |
Steering: | Single Point |
Chassis Type: | Modified Tub |
Chassis Material: | Composite Nylon |
Top Speed: | 30+mph |
Skill Level: | 1 |
Battery Tray Dimensions: | 164 mm x 46 mm x 26 mm |
Required Items: | NiMH or LiPo Battery, Charger, 4 "AA" Batteries (Transmitter) |
ESC Specs | |
Input voltage: | 4-7 Cells (4.8 to 8.4 Volts DC) |
Case Size: | 31 mm x 55 mm x 15.5 mm |
Weight: | 2.44 ounces |
Motor Limit: | 15-turns (540 Size) 12-turns (550 Size) |
On Resistance Forward: | 0.007 Ohms |
On Resistance Reverse: | 0.014 Ohms |
BEC Voltage: | 6.0 VDC |
BEC Current: | 1A |
Power Wire: | 14 Gauge / 5 inches |
Input Harness Wire: | 26 Gauge / 9 inches |
PWM Frequency: | 1600 Hz |
Low Voltage Detection (LVD): | 2-Stage indicators, switchable (on or off) |
Thermal Protection: | Thermal shutdown |
Profile selection: |
Sport Mode: 100% FWD, 100% brakes, 100% REV Race Mode: 100% FWD, 100% brakes, no REV Training Mode: 50% FWD, 100% brakes, 50% REV |
Single-button setup: | Yes, Traxxas EZ-Set |
Select the right Traxxas iD battery to fit your needs from the options below | |||
---|---|---|---|
Runtime* | 15+ Minutes | 20+ Minutes | 30+ Minutes |
Battery |
TRA2923X (1) 3000mAh 8.4V NiMh |
TRA2950X (1) 4200mAh NiMH |
TRA2843X (1) 5800mAh 2S LiPo |
Skill Level | 1 | 1 | 1 |
*Runtimes are estimates; actual runtime will vary due to operating conditions and driving style. |
